Material characteristics & hardness: Chip flow depends on material type and feed rate. Ability of the tooling setup to mitigate vibrations. Power available at the spindle (to prevent stalling of the cutter or workpiece). Depth of Cut (for example a high feed tool like HRM Double may have a small depth of cut at just 1mm, whereas a traditional 90 degree mill like ALPHA MILL may have a large depth of cut of 8mm). Type of tool (for example a high feed tool like HRM Double may feed at 1.6mm per tooth, whereas a traditional 90 degree mill like ALPHA MILL may have a feed rate of just 0.25mm per tooth). It can be expressed thus for milling also, but it is often expressed in units of distance per time for milling (typically millimetres per minute), with considerations of how many teeth (or flutes) the cutter has then determined what that means for each tooth. It is expressed in units of distance per revolution. To extend the life of your tooling, use adequate lubrication.Feed rate is the velocity at which the cutter is fed against the workpiece. CBN only smears the aluminum when removing metal without producing the necessary finish today’s aluminum heads require. Primarily used to machine non-ferrous materials at high speeds, PCD has been developed specifically to machine aluminum. PCD (Polycrystalline Diamond) is an ultra-hard tool material (substrate) consisting of a synthetic polycrystalline diamond tip brazed to a carbide insert carrier. If the tip isn’t fractured, it can be lapped back to spec, extending the life of the tip. There’s nothing worse than having your machine throw a $250 tool bit somewhere in the shop, because chances are you are not going to find it. It’s essential that when you rotate the tip, that the holder is clean and the holding finger is sound.
Plus if you’re using a solid CBN tip, after one side is worn out you simply flip it over and use it again. These tips can be rotated about every 2-3 degrees so you can get the maximum life out of the tip. Plus the titanium coating delivers longer life. I recommend the titanium coated CBN tips, due to the witness mark left on the tip after you have surfaced a workpiece. The purity of CBN content separates price from quality. As I stated earlier, some CBN machines are simply converted wet grinders, and others are designed as CBN machine. CBN must be driven by rigid machine tools with secure holding fixtures. With that in mind it’s even more critical to have correct speeds and feeds on your surfacer to adjust for machining cylinder heads and blocks. Guess what? The average cylinder head or block has many holes that interrupt the cutting action of the tool bit.
It likes to cut large amounts of material with out interruption. It’s available either as a tip brazed to a carbide insert carrier or as a solid insert.ĬBN has its limitations. The aggressive cutting action it delivers is directly related to how true the set up is and how conscientious the operator is.ĬBN, an ultra-hard cutting material consisting of polycrystalline cubic boron nitride with a metallic or ceramic binder is primarily used to machine hardened ferrous material.
Others have been designed to be a CBN cutting machine. Some machines are just wet grinders converted to use a CBN bit. There has been quite a rush to CBN (Cubic Boron Nitride) in cutting iron in the last ten years.
